Aqara Smart Lock U200 Kit
Aqara Smart Lock U200 Kit
20 in stock
Couldn't load pickup availability
FAQ:
1. Is a Smart Lock U200 compatible with a door without a handle?
Yes, the U200 can pull the latch, making it suitable for doors with handles or those with only a keyhole. To use this function, enable the "Pull Spring Feature" in the settings of Aqara Home app.
2. What kind of lock is compatible with the U200?
Compatible Locks: EU Mortise Lock, US Deadbolt Lock
Compatible Cylinders: EU Profile Cylinder / Select Scandi Profile Cylinder / UK Oval Cylinder / Schlage and Kwikset Standard Cylinder
* This compatible list will keep updating.
Keywords: dbgtech, Aqara, Aqara India, Apple HomeKit
Specifications:
|
Product Name |
Aqara Smart Lock U200 Kit |
|
Model |
EL-D02D |
|
Dimensions |
Door Lock Dimensions: 62.3 × 60.6 × 152.5 mm (2.4 × 2.4 × 6 in.) Keypad Dimensions: 42.7 × 33 × 146 mm (1.7 × 1.3 × 5.7 in.) |
|
Power Input |
Door Lock: Aqara Rechargeable Li-ion Battery 7.4V Keypad: 4 LR3 AAA 1.5V Batteries 12V-24V AC 0.2A 50/60Hz or 12V-24V DC 0.5A wired input |
|
Wireless Protocols |
Thread, Bluetooth 5.1, NFC |
|
Operating Temperature |
-15 °C~66 °C (5 °F~ 150.8 °F) |
|
Operating Humidity |
0 ~ 93% RH, no condensation |
|
What is in the Box |
Smart Lock U200 × 1, User Manual × 1, Aqara Rechargeable Battery × 1, Cylinder Adaptor Kit × 1, Hexagon Screwdriver × 1, USB-C to USB-A Cable × 1, AAA Battery × 4, 3M Sticker × 1, EVA Pad Kit × 1, Screw Kit × 1, Power Bank Pouch × 1, Replaceable Panel × 1, NFC Card × 1, AA Battery Adapter × 1 |
